About the product
8W DC/DC converter, input 9..36V, output 15V/0.53A
Technical data
- Meets standard railroad approval EN50155
- DIP 24 housing with standard pinout
- 4:1 Wide entrance area
- Wide temperature range -40°C..+85°C
- No minimum load required
- Fully encapsulated
- Protective circuits: Short circuit/overload/overvoltage/undervoltage
- 3kVdc insulation
- Remote ON/OFF control
- 3-year guarantee
- Manufacturer MEAN WELL
Product specifications
| Manufacturer | MEAN WELL |
| I/O isolation | 3000 VDC |
| Additional functions | Remote ON/OFF |
| Design | DIP24 |
| Output current | 530 mA |
| Height | 10.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Power | 8 W |
| Output voltage (VDC) | 15 V |
| Application | Railroad, ITE/AV |
Data sheets
