About the product
9W DC/DC converter, input 9..36V, output 12V/0.75A
Technical data
- Highest power density in 8-PIN SIP housing
- 4:1 wide input voltage range
- Smallest PCB with 9 watts
- -40°C to +85°C Temperature range
- Efficiency 89%
- Permanent short-circuit resistance
- 1600Vdc I/O isolation
- Remote On/Off Control
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Design | SIP8 |
| Additional functions | Remote ON/OFF |
| Manufacturer | Motes |
| Height | 11.2 mm |
| Width | 9.6 mm |
| Length | 21.8 mm |
| Output current | 750 mA |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Power | 9 W |
| I/O isolation | 1600 VDC |
Data sheets
