5kW DC/AC UPS inverter with charging and UPS function 280...430Vdc/230Vac

NTN-5K is an all-in-one device that supports AC/DC charging, DC/AC conversion and AC bypass. NTN-5K is also suitable for external solar modules and MPPT-Chargeurs. The main features include five important highlights:

1. built-in high power AC-DC charger with 4520W and fast charging function
. 2. modular design with a 5KW module that allows flexible parallel connection of AC outlets up to 30KW (1+5 units) for flexible power increase
. 3. the chassis is designed in a 2U high housing for easy installation and quick mounting in a standard 19" rack
. 4. 3 pieces of single phase NTN-5K can be combined to 3-phase 3Ø4W AC output
. 5. provides a comprehensive control and monitoring platform via the CMU2E, CM2E-R controller

Technical data

• Combines charger, inverter, AC bypass and integrated MPPT solar charger support.
• AC charger with up to 4250W power
• UPS function without interruption (<10ms)
• True sine wave (THD <3%)
• Parallel switchable up to 30kW (5+1)
• Temperature-controlled fan
• AC output and frequency adjustable via DIP switch
• Protective circuits: Reverse polarity protection / DC low alarm / DC low shutdown / overvoltage / short circuit / overload / overtemperature
• Deep discharge protection
• -30°C to +70°C
• Suitable for lead batteries and lithium batteries
• Supports MODBus / CANBus
• Protective coating standard
• 5 year guarantee
