About the product
IRM-90-24 is a compact 90W AC/DC power supply unit for direct mounting on the PCB.
IRM-90 covers an input range from 85 to 305Vac and is built into a flame-retardant plastic housing.
Technical data
- Input voltage 80 to 305Vac
- No load power consumption 0.21W
- Very compact design
- EN55032 Class B without additional components
- Protection class II Device without earth connection
- Overvoltage category III
- Short-circuit, overload and overvoltage protection
- Dimensions 87 x 52 x 29.5mm (L x W x H)
Product specifications
| Length | 87 mm |
| Output voltage (VDC) | 24 V |
| Manufacturer | MEAN WELL |
| Height | 29.5 mm |
| Power | 90 W |
| Width | 52 mm |
| Input voltage range (VAC) | 85-305 V |
| Application | Budget, ITE/AV |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, UL62368-1 / ITE, OVC III |
