About the product
IRM-02-5S is a Class II AC/DC power supply for direct soldering on the PCB. SMD version
Technical data
- Input voltage 85 to 305Vac
- No load power consumption <0.075W
- Very compact design
- SMD version
- Protection class II Device without earth connection
- Short-circuit, overload and overvoltage protection
- Dimensions 33.7 x 22.2 x 16mm (L x W x H)
Product specifications
| Manufacturer | MEAN WELL |
| Height | 16 mm |
| Output voltage (VDC) | 5 V |
| Application | ITE/AV |
| Length | 33.7 mm |
| Width | 22.2 mm |
| Input voltage range (VAC) | 85-305 V |
| Certificates | EN62368-1 / ITE, UL62368-1 / ITE |
| Power | 2 W |
