About the product
IRM-60-12 is a compact 60W AC/DC power supply unit for direct mounting on the PCB.
IRM-60 covers an input range from 85 to 305Vac and is built into a flame-retardant plastic housing.
Technical data
- Input voltage 85 to 264Vac
- No load power consumption <0.1W
- Very compact design
- Protection class II Device without earth connection
- Short-circuit, overload and overvoltage protection
- Dimensions 87 x 52 x 29.5mm (L x W x H)
Product specifications
| Length | 87 mm |
| Manufacturer | MEAN WELL |
| Output voltage (VDC) | 12 V |
| Power | 60 W |
| Height | 29.5 mm |
| Width | 52 mm |
| Input voltage range (VAC) | 85-305 V |
| Application | Budget, ITE/AV |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, UL62368-1 / ITE, OVC III |
