About the product
IRM-03-9S is a Class II AC/DC power supply for direct soldering on the PCB. SMD version
Technical data
- Input voltage 85 to 305Vac
- No load power consumption <0.075W
- Very compact design
- SMD version
- Protection class II Device without earth connection
- Short-circuit, overload and overvoltage protection
- Dimensions 37 x 24 x 16mm (L x W x H)
Product specifications
| Manufacturer | MEAN WELL |
| Power | 3 W |
| Length | 37 mm |
| Height | 16 mm |
| Application | ITE/AV |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, UL62368-1 / ITE |
| Input voltage range (VAC) | 85-305 V |
| Output voltage (VDC) | 9 V |
| Width | 24 mm |
