About the product
CFM25S family is a Class II AC/DC power supply with high power density and compact dimensions. Version for direct soldering on the PCB.
Technical data
- Input voltage range 90 to 264Vac
- Efficiency 87%
- No load power consumption <0.1W
- Protective circuit: short circuit and overvoltage
- Complies with EN55032 Class B and CIRSS/FCC Class B
- Complies with IEC62368-1, UL62368-1 and IEC/EN60335-1, IEC61558-1
- Approval Industry IEC/UL/EN60950-1
- Peak Power (2x Rated Power)
- Class II
- Dimensions (suffix -E) 53.1 x 30.3 x 24.8mm (L x W x H)
Product specifications
| Power | 25 W |
| Output voltage (VDC) | 36 V |
| Input voltage range (VAC) | 90-264 V |
| Manufacturer | Cincon |
| Length | 53.1 mm |
| Width | 30.3 mm |
| Height | 24.8 mm |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, UL62368-1 / ITE |
| Application | Budget, ITE/AV |
