About the product
DRDN-20-48 is a 20A redundancy module which can be used to improve the reliability of the overall system. The MOSFET technology used increases the efficiency and reduces the voltage drop between input and output voltage. One DC OK relay contact per channel is built in for monitoring.
Technical data
- Supports 1+1 and N+1 redundancy systems
- 2 channels input and 1 channel output
- Output current up to 20A
- Input current per channel 10A x 2 or 20A x 1
- Efficiency 98%
- Voltage drop 0.25Vdc maximum
- 2-channel DC OK signal and alarm relay contact
- Dimensions 32 x 125.2x 102mm (W x H x D)
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Width | 32 mm |
| Manufacturer | MEAN WELL |
| Output voltage (VDC) | 48 V |
| Height | 125.2 mm |
| Depth | 102 mm |
| Product series | DRDN |
| Certificates | IEC62368-1, EAC TP TC 004, UL62368-1 |
