About the product
DRC-60A is a 60W DIN rail power supply unit with UPS function. In addition to the main output, the power supply unit has a charging output for connecting a backup battery.
Technical data
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- Output voltage adjustable with internal potentiometer
- With battery charging function for UPS operation
- Alarm signal for AC OK and battery low via relay contact
- Operating temperature range from -30°C to +70°C
- LED display for DC OK
- Dimensions 40 x 90 x 100mm (W x H x D)
Product specifications
| Width | 40 mm |
| Certificates | EN62368-1, UL62368-1, LPS |
| Overload behaviour | Hiccup mode |
| Additional functions | Battery charger, UPS function |
| Power | 59 W |
| Output voltage (VDC) | 13.8 V |
| Depth | 100 mm |
| Height | 90 mm |
| Output current | 2.8 A |
| Input voltage range (VAC) | 90-264 V |
| Manufacturer | MEAN WELL |
| Product series | DRC |
