120W DIN rail power supply 48V/2.5A, 1 or 2-phase

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The WDR-120-48 DIN rail power supply unit is designed for operation with one or two phases. Thanks to the wide input range of 180 to 550Vac, the power supply unit is also particularly robust in unstable networks with high voltage peaks.

Technical data

1+2 phase input voltage 180 to 550Vac
Suitable for mounting on TS-35/7.5/15 top-hat rails
Operating temperature range from -25°C to +70°C
LED display for DC OK
Built-in DC OK relay contact
Dimensions 40 x 125.2 x 113.5mm (W x H x D)

Product specifications

Width	40 mm
Certificates	IEC62368-1, UL508
Input voltage range (VAC)	180-550 V
Depth	113.5 mm
Product series	WDR
Status signals	DC OK relay contact
Height	125.2 mm
Power	120 W
Output current	2.5 A
Output voltage (VDC)	48 V
Manufacturer	MEAN WELL
Overload behaviour	Constant current limiting
