20W DIN rail power supply 12V/1.67A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The compact MEAN WELL MDR-20-12 DIN rail power supply unit in a plastic housing saves space in the control cabinet. A DC-OK signal is integrated for remote monitoring.

Technical data

No load power consumption 0.75W
Suitable for mounting on TS-35/7.5/15 top-hat rails
LED display for DC OK
Dimensions 22.5 x 90 x 100mm (W x H x D)

Product specifications

Manufacturer	MEAN WELL
Overload behaviour	Constant current limiting
Width	22.5 mm
Product series	MDR
Depth	100 mm
Height	90 mm
Power	20 W
Output current	1.67 A
Input voltage range (VAC)	90-264 V
Output voltage (VDC)	12 V
Certificates	EN62368-1, AS/NZS62368-1, CNS15598-1, EAC TP TC 004, UL508
