50W DIN rail power supply unit 5V/10A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The compact MEAN WELL MDR-60-5 DIN rail power supply unit in a plastic housing saves space in the control cabinet. A DC-OK relay contact is installed for remote monitoring.

Technical data

No load power consumption 0.75W
Suitable for mounting on TS-35/7.5/15 top-hat rails
LED display for DC OK
DC OK relay contact
Dimensions 40 x 90 x 100mm (W x H x D)

Product specifications

Width	40 mm
Overload behaviour	Constant current limiting
Output voltage (VDC)	5 V
Product series	MDR
Depth	100 mm
Height	90 mm
Status signals	DC OK relay contact
Input voltage range (VAC)	85-264 V
Power	50 W
Output current	10 mA
Manufacturer	MEAN WELL
Certificates	EN62368-1, IEC62368-1, CNS14336-1, EAC TP TC 004, UL62368-1, UL508
