90W DIN rail power supply 12V/7.5A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The compact MEAN WELL MDR-100-12 DIN rail power supply unit in a plastic housing saves space in the control cabinet. A DC-OK relay contact is installed for remote monitoring.

Technical data

No load power consumption 1.0W
Suitable for mounting on TS-35/7.5/15 top-hat rails
LED display for DC OK
DC OK relay contact
Dimensions 55 x 90 x 100mm (W x H x D)

Product specifications

Manufacturer	MEAN WELL
Overload behaviour	Constant current limiting
Product series	MDR
Depth	100 mm
Height	90 mm
Status signals	DC OK relay contact
Width	55 mm
Output current	7.5 A
Power	90 W
Input voltage range (VAC)	90-264 V
Output voltage (VDC)	12 V
Certificates	EN62368-1, CNS14336-1, EAC TP TC 004, UL508
