About the product
NDR-120-48 is a cost-effective, slim 120 Watt DIN rail power supply for mounting on TS-35/7.5 or TS35/15 mounting rails. The complete protection functions and the corresponding certifications for industrial control devices (UL508, TUV BS EN62368-1) make the NDR-120 a very competitive power supply solution for industrial applications.
Technical data
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- Operating temperature range from -20°C to +70°C
- LED display for DC OK
- Dimensions 40 x 125.2 x 113.5mm (W x H x D)
Product specifications
| Width | 40 mm |
| Overload behaviour | Constant current limiting |
| Product series | NDR |
| Depth | 113.5 mm |
| Height | 125.2 mm |
| Input voltage range (VAC) | 90-264 V |
| Power | 120 W |
| Output current | 2.5 A |
| Output voltage (VDC) | 48 V |
| Manufacturer | MEAN WELL |
| Certificates | EN62368-1, IEC62368-1, UL508 |
