40W DIN rail power supply 24V/1.7A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The compact MEAN WELL MDR-40-24 DIN rail power supply unit in a plastic housing saves space in the control cabinet. A DC-OK relay contact is installed for remote monitoring.

Technical data

No load power consumption 0.75W
Suitable for mounting on TS-35/7.5/15 top-hat rails
LED display for DC OK
DC OK relay contact
Dimensions 40 x 90 x 100mm (W x H x D)

Product specifications

Output voltage (VDC)	24 V
Overload behaviour	Constant current limiting
Product series	MDR
Depth	100 mm
Height	90 mm
Status signals	DC OK relay contact
Output current	1.7 A
Input voltage range (VAC)	90-264 V
Power	40 W
Manufacturer	MEAN WELL
Width	40 mm
Certificates	EN62368-1, CNS14336-1, EAC TP TC 004, UL62368-1, UL508
