300W Open Frame Power Supply 24V/12.5A, ITE, Medical, Household

LOP-300 is a 4x2 300W open frame power supply with low height and high power density. The power supply can be used in both Class I and Class II applications. Comprehensive safety approvals for ITE, household and medical applications make the LOP-300 a high-performance power supply unit for a wide range of applications.

Technical data

• 4x2 Power supply unit with only 25.4mm height
• 80-264Vac wide input range with PFC
• No load power consumption <0.5W
• Global certifications for ITE, household and medical applications
• 150% peak load for 3 seconds
• 180W convection-cooled, 300W with forced ventilation
• Overvoltage category III (OVC III)
• -40 to +80°C Operating temperature range
• Leakage current < 500uA
• Approved operating altitude 5000M
