420W medical power supply 12V/35A

The Medical LFM420M series from Cincon sets a new standard for efficiency with its compact housing. It meets the requirements of 2xMOPP. Its innovative design with a semi-encapsulated housing and baseplate cooling ensures exceptional performance in a variety of scenarios. With its flat 1-inch profile, it offers a powerful yet space-saving solution.

Technical data

• High power density up to 25W/inch³
• No load power consumption <0.5 Watt
• Continuous short-circuit protection
• Overtemperature protection
• Overvoltage protection
• Active PFC complies with EN61000-3-2
• Certified according to IEC/ES/EN60601-1 2x MOPP
• Certified according to IEC/UL/EN62368-1
• Complies with IEC/EN60335-1
• Operating altitude 5000m
• Optional: with threaded hole M3 for mounting (suffix -C0, instead of standard through-hole Ø 3.2mm)
