2300W power supply unit or charger 55V/41.8A

HEP-2300-55 is an industrial AC/DC power supply unit with an output of 2300 W. Thanks to its robust design, the power supply unit can work in very humid, dusty, oily and vibration-intensive environments. The entire series is built into an aluminum housing and fully encapsulated with thermally conductive adhesive. With the built-in charger function (installable via CANBus or with SBP-001 interface), the power supply can also be used as a charger for lead and lithium batteries. In addition to the high efficiency of up to 95.5%, the entire series operates from -40°C to +70°C under convection without a fan. HEP-2300 has full protection functions and 10G anti-vibration capability; it complies with international safety regulations such as TUV EN62368-1, UL62368-1, and the design refers to EN61558-1 and EN60335-1. The HEP-2300 series is suitable as a powerful power supply solution for various industrial applications.

Technical data

• High voltage output
• 95% High efficiency
• Fanless, convection cooled
• Built into aluminum housing and encapsulated
• Meets 10G vibration test
• CANBus interface
• Output voltage and output current Programmable
• Can be used as a charger for lead or lithium batteries
• Remote ON/OFF
