198W power supply unit 3.3V/60A

Delivery at your place between May 22 and Jun 26 2025

Add to cart

About the product

UHP-350-3.3 is a slim power supply unit in a housing with a height of just 26 mm. Thanks to its industrial and household approvals, this high-quality power supply unit can be used in a wide range of applications such as industrial automation, household appliances, LED displays and much more.

Technical data

Input voltage 90 to 264Vac
with active PFC
Operating temperature range from -30°C to +70°C
Holds surge voltages up to 300Vac for up to 5 seconds
Approved for operation up to 5000 meters altitude
Dimensions 220 x 62 x 31mm (L x W x H)

Product specifications

Manufacturer	MEAN WELL
Maximum VDC setting range	3.5 V
Application	Budget, ITE/AV
Power	198 W
Output voltage (VDC)	3.3 V
Protection class	Class I
Height	31 mm
Width	62 mm
Input voltage range (VAC)	90-264 V
Length	220 mm
Minimum VDC setting range	3.4 V
