336W power supply 24V/14A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

HRPG-300-24 is a robust switching power supply with integrated fan for applications with high demands on service life and reliability with stand-by function

Technical data

Input voltage 85 to 264Vac
With active PFC
Remote On/Off
Standby 5V@0.3A
Remote Sense function
Power consumption at no load <0.5W
Air cooling with integrated fan
Operating temperature range from -40°C to +70°C
Withstands surge voltages up to 300Vac for up to 5 seconds
Dimensions 199 x 105 x 41mm (L x W x H)

Product specifications

Output voltage (VDC)	24 V
Control signals	Remote ON/OFF, Remote Sense
Minimum VDC setting range	21.6 V
Maximum VDC setting range	28.8 V
Width	105 mm
Power	336 W
Status signals	DC OK signal
Protection class	Class I
Application	ITE/AV
Input voltage range (VAC)	85-264 V
Height	41 mm
Length	199 mm
Manufacturer	MEAN WELL
Additional functions	5VDC auxiliary output
