About the product
PSP-600-48 is a 600W switching power supply with extensive functions.
Technical data
- Input voltage 85 to 264Vac
- with active PFC
- Metal housing with screw terminals
- Remote ON/OFF function
- DC OK signal
- Remote sense function for voltage equalization with long cables
- Overload circuit with constant current limiting
- Operating temperature range from -20°C to +60°C
- Dimensions 170 x 120 x 93mm (L x W x H)
Product specifications
| Width | 120 mm |
| Maximum VDC setting range | 56 V |
| Additional functions | Parallel switchable |
| Control signals | Remote ON/OFF, Remote Sense |
| Height | 93 mm |
| Status signals | DC OK signal |
| Input voltage range (VAC) | 88-264 V |
| Protection class | Class I |
| Application | ITE/AV |
| Length | 170 mm |
| Power | 600 W |
| Output voltage (VDC) | 48 V |
| Manufacturer | MEAN WELL |
| Minimum VDC setting range | 41 V |
