About the product
HEP-480-24A is a robust power supply unit for harsh environmental conditions. Thanks to its fully encapsulated construction, the power supply unit is designed for use in damp, dusty, oily and vibrating environments.
Technical data
- Input voltage 90 to 305Vac
- with active PFC
- Current and voltage adjustable on the power supply unit
- IP65 design splash-proof
- designed for operations up to max. 5000m.a.s.l. operating altitude
- Very robust design with a long service life
- Fully encapsulated in aluminum housing
- Suitable for use in a harsh environment with high dust density, humidity, vibration and altitude
- Operating temperature range from -55°C to +65°C
- Surge immunity up to 6kV
- Vibration test up to 10G
- Dimensions 262 x 125 x 43.8mm (L x W x H)
Product specifications
| Output voltage (VDC) | 24 V |
| Maximum VDC setting range | 25.2 V |
| IP protection | IP65 |
| Protection class | Class I |
| Application | ITE/AV |
| Input voltage range (VAC) | 85-264 V |
| Width | 125 mm |
| Length | 262 mm |
| Power | 480 W |
| Height | 43.8 mm |
| Manufacturer | MEAN WELL |
| Minimum VDC setting range | 20.4 V |
