About the product
1-hole seal/grommet for various plugs with cable glands from Techno, Italy with wrench size 24 mm
. 2-part reducing grommet for use with cables with an outer diameter of Ø 6.5 - 8.5 mm, or Ø 7.5 - 9.0 mm after removing the inner seal
Outer diameter: Ø 16.3 x 9.8 mm
Inner diameter/for cables with outer diameter: Ø 6.5 - 8.5mm / Ø 7.5 - 9.0 mm
For other multi-hole gaskets and reducing sleeves from Techno and compatibility, see data sheets
Other, unpublished Techno products and designs on request.
Technical data
Dimensions: Ø 16.3 x 9.8 mm
Inner diameter/for cable with outer diameter: Ø 7.5 - 9.0 mm, with reduction Ø 6.5 - 8.5mm
Color: Techno green
Cable glands: 1
Temperature range: -40°..+100°C
Material: TPE
Characteristics: Halogen-free, silicone-free
Subject to errors and technical changes
Product specifications
| Manufacturer | Techno |
| Product | Sealing rings |
