Mini circular device connector M25, 2p, socket, screw connection, 0.5-2.5mm2, IP66/IP68

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

2-pin M25 mini round socket TH387 with screw lock from Techno

Version: Device socket, wire protection
. Connection: Screw
. Locking: Screw

Counterpart: THB.387.A2A / THB.387.A2A.L

Also available as a set with circular connector THB.387.EF2A

Other Techno products and designs on request.

Technical data

Number of poles: 2
Protection class: IP66/IP68
Thread: M25
For max. panel thickness: 7 mm
Cable cross-section: 0.5 - 2.5 mm2
Rated voltage: 500V AC
Rated current: 17.5 A AC/DC
Temperature range: -40°C..+125°C
Manufacturer: Techno

Subject to technical changes

Product specifications

Connection	Screw terminal
Connection cross-section (mm²)	0.5 - 2.5 mm²
Temperature range	-40°C to 125°C
IP protection	IP66 - IP68
Product	Cable socket
Certificates	CE
Nominal voltage (V)	500 V
Nominal current	17.5 A
Manufacturer	Techno
Number of poles	2
