About the product
SRPL-2305N-30CC250-850 is a flexible, dimmable LED converter with constant current output. The power supply unit can be controlled with DALI2 DT6. The output current can be set between 250 and 850mA via NFC.
In a slim linear 30 x 21mm aluminum housing, ideal for profiles and linear luminaires.
Control
- DALI2 DT6, AC-PUSH
Application
- Single Color
Current setting
- NFC
Dimming range
The load-dependent dimming range is 0.1% to 100%
Dimming method: Amplitudes/CCR
Technical data
- DALI2 DT6 and AC-PUSH dimmable 1-channel NFC power supply unit
- 1 channel 250~850mA constant current output, selectable via NFC program tool
- In accordance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2
- Built-in DALI-2 interface, DALI DT6 device
- Setting the DALI address/group/scene via the NFC program tool
- Dimmable LED driver. Max. output power 30W
- Output voltage range: 10-54VDC
- Class 2 power supply unit
- High power factor and efficiency
- For switching and dimming LED lighting fixtures
- Amplitude dimming, smooth and deep dimming down to 0.01%
- Compatible with universal DALI masters that support DT6 commands
- Protection class IP20
- 5 year guarantee
- Dimensions: 243 x 30 x 21mm
DOWNLOAD SR NFC TOOL
ANDROID APPLE
Product specifications
| Manufacturer | Sunricher |
| Connection | Spring clamp |
| Manufacturer's warranty | 5 years |
| IP protection | IP20 |
| Length | 243 mm |
| Current setting | NFC |
| Power | 30 W |
| Control | DALI, AC Push Dimming |
| Width | 30 mm |
| Channels | 1 |
| Application | Single color |
| Height | 21 mm |
| Dimming type | Current control |
