About the product
- Rectangular Tunable White LED module with an adjustable color temperature from 2700K to 6500K (= one print for 2700K or 6500K)
- This module can also be operated as a standard 2700K or 6500K version, as both color temperatures can be controlled individually.
- High module efficiency (constant current)
- Very high color rendering Ra >90
- Very narrow color tolerance (MacAdam 3)
- Ideal for area lighting
Product specifications
| Operating mode | CC |
| PCB material | FR-4 |
| Application | Single Color, Tunable White |
| Colour temperature (K) | 2700, 6500 K |
| Light colour | Cold white|Warm white |
| Colour rendering Ra | 90 |
| Forward current | 200 mA |
| Forward voltage | 26.8 V |
| Power | 5.4 W |
| Length | 289 mm |
| Width | 119 mm |
| Shape | Linear |
| Luminous flux | 827-865 lm |
